4.3 Inch 480X272 MCU 16bit Resistive Touch Panel Screen Board Controller SSD1963, BX1, R26

DescriptionThis 4.3″ TFT LCD Module can be can be easy controlled by MCU such as 8051, PIC, AVR, ARDUINU, and ARM .It can be used in any embedded systems which require display high quality colorful image. The Module used SSD1963 LCD controller .This LCD has a superior display quality and super wide viewing angle,  SSD1963 is a display controller of 1215K byte frame buffer to support up to 864 x 480 x 24bit graphics content.  It also equips parallel MCU interfaces in different bus width to receive graphics data and command from MCU.  Its display interface supports common RAM-less LCD driver of color depth up to 24 bit-perpixel. Features:Size : 4.3”TFTDisplay Type : 16.7M TFT,TramsmissiveViewing Direction : 12 O’ClockSSD1963 touch panel controllerDriving IC : OTA5180ABlacklight : 10-Chip WHITE LEDModule Dimensions: 114.0 * 68.0Panel Dimensions: 67.2 * 105.5Visual area (VA): 63.0 * 102.04Display Area (AA): 53.86 * 95.04Resolution: 480 * 272Drive voltage: 2.8V-3.3VInterface Type: 16 parallelOperating Temperature : -20 degree~ 70degreeStorage Temperature : -30degree ~ 80degree2*20 Pin 2.54mm double row pin header interface for connecting MCU.Interface Definition:NumberPin LabelDescription1GNDModule power ground pin2VDDModule power positive pin (module has integrated voltage regulator IC, so the power supply can be connected to 3.3V)3NCUndefined, reserved4RSLCD register / data selection control pin(high level: register, low level: data)5WRLCD write control pin6RDLCD read control pin7~14DB8~DB16LCD data bus DB8~DB1615CSLCD reset control pin(low level enable)16F_CSFlash chip select control pin (used when using the Flash extension function, this test program is not used)17RESTLCD reset control pin( low level reset)18NCUndefined, reserved19LED-ALCD backlight power positive pin20NCUndefined, reserved21~28DB0~DB7LCD data bus DB0~DB729T_CLKTouch screen SPI bus clock control pin30T_CSTouch screen IC chip select control pin(Low level enable)31T_DINTouch screen SPI bus data input pin32NCUndefined, reserved33T_DOTouch screen SPI bus data output pin34T_IRQTouch screen interrupt detection pin35SD_DOSD card bus data output pin36SD_CLKSD card clock control pin37SD_DINSD card bus data input pin38SD_CSSD card selection control pin39~40NCUndefined, reserved
